PKM 200 Tipper trailers
The PKM 200 tipper trailers, with a gross weight of 20 tons, are designed for professional municipal and construction applications.
They are equipped with a 27.6 m³ tipper body made of high-strength special steel, ensuring long service life and resistance to intensive working conditions.
The trailer features an INFO center with an integrated scale, allowing precise monitoring of loading and transport, while axles from reputable manufacturers guarantee reliability and stability during operation.
The rear tipper doors can be configured as barn-style and/or swinging doors, depending on the user’s requirements.
Technical specifications:
- Internal dimensions of the trailer: 6000 x 2300 x 2000 mm
- Own weight: ≈5570 kg
- Payload: ≈12340 kg
- Body volume: 27.6 m³
- Profiled “Z” sides made of special high-strength steel, 3.0 mm thick
- Steel floor made of durable 5.0 mm thick steel
- INFO center with scale
- Rear doors: barn-style and/or swinging
- Gross weight: 20 t
